3D Scanning and 3D Modelling for Thickener Feed Flange Replacement

3D laser scanning is used to accurately capture the existing geometry of the mining thickener feed well and surrounding structures, ensuring all critical dimensions and interface points are recorded. The scan data is converted into a precise 3D model, which is then used to design a replacement flange that fits seamlessly within the existing installation. This workflow minimises site rework, reduces fabrication risk, and ensures accurate alignment during installation, resulting in faster turnaround, improved safety, and higher confidence in the final fit.
